10GBASE-SR SFP Module, Industrial Temperature
10GBASE-SR, 10GBASE-SW and OTU2e 850nm MMF, Spare
Part#:
SFP-10G-SR-I=
Manufacturer:
Cisco
Excl. VAT: £510.29
RRP: £739.19
Save: 31%
In stock
The Cisco SFP-10G-SR-I is a multirate 10GBASE-SR, 10GBASE-SW and OTU2/2e module for industrial operating temperature range. This module also supports CPRI datarate options 3, 4, 5, 6, 7, 7a, 8. It supports a link length of 26m on standard Fiber Distributed Data Interface (FDDI)-grade Multimode Fiber (MMF). Using 2000MHz*km MMF(OM3), up to 300m link lengths are possible. Using 4700MHz*km MMF (OM4), up to 400m link lengths are possible.
More Information
Part#
SFP-10G-SR-I=
EAN
0889728413084
Specification
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Fiber optic connector | LC |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u |
| Maximum transfer distance | 400 m |
| Wavelength | 850 nm |
| Fiber cable diameters supported (core/cladding) | 50/125 µm |
| Tx power (min) | -1.2 dBmW |
| Tx power (max) | -7.3 dBmW |
| Rx power (min) | -1 dBmW |
| Rx power (max) | -9.9 dBmW |
| Duplex system | Full |
| Maximum data transfer rate | 10000 Mbit/s |
| Interface type | SFP+ |
| Multi-mode fiber (MMF) supported | Yes |
| SFP transceiver standard | SR |
| Product colour | Metallic |
| Plug and Play | Yes |
| Hot-swap | Yes |
| Features | |
| Product colour | Metallic |
| Plug and Play | Yes |
| Hot-swap | Yes |
| Certification | MSA |
| Power | |
| Power consumption (typical) | 1 W |
| Certificates | |
| Certification | MSA |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 85 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Network | |
| SFP transceiver type | Fiber optic |
| Fiber optic connector | LC |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u |
| Maximum data transfer rate | 10000 Mbit/s |
| Interface type | SFP+ |
| Technical details | |
| Plug and Play | Yes |
| Hot-swap | Yes |
| Maximum transfer distance | 400 m |
| Wavelength | 850 nm |
| Fiber cable diameters supported (core/cladding) | 50/125 µm |
| Tx power (min) | -1.2 dBmW |
| Tx power (max) | -7.3 dBmW |
| Rx power (min) | -1 dBmW |
| Rx power (max) | -9.9 dBmW |
| Duplex system | Full |
Manufacturer
Cisco
