100GBASECWDM4QSFPTransciver,LC,2kmoverSMF REMANUFACTURED
100G QSFP28 Transceiver 100G ER-Lite 2km
Part#:
QSFP-100GCWDM4S-RF
Manufacturer:
Cisco
Excl. VAT: £7,927.12
Available to Backorder: contact for lead time
The Cisco® 100GBASE Quad Small Form-Factor Pluggable (QSFP) portfolio offers customers a wide variety of high-density and low-power 100 Gigabit Ethernet connectivity options for data center, high-performance computing networks, enterprise core and distribution layers, and service provider applications. The QSFP-100G modules are our new generation of 100G transceiver modules solution based on a QSFP form factor.
The Cisco QSFP-100G-PSM4-S Module supports link lengths of up to 500 meters over SMF with MPO connectors. The 100 Gigabit Ethernet signal is carried over 12-fiber parallel fiber terminated with MPO multifiber connectors.
The Cisco QSFP-100G-PSM4-S Module supports link lengths of up to 500 meters over SMF with MPO connectors. The 100 Gigabit Ethernet signal is carried over 12-fiber parallel fiber terminated with MPO multifiber connectors.
More Information
Part#
QSFP-100GCWDM4S-RF
Specification
| Network | |
|---|---|
| SFP transceiver type | Fiber optic |
| Fiber optic connector | LC |
| Maximum data transfer rate | 100000 Mbit/s |
| Interface type | QSFP |
| Technical details | |
| Hot-swap | Yes |
| Maximum transfer distance | 2000 m |
| Tx power (min) | -9.4 dBmW |
| Tx power (max) | 2 dBmW |
| Rx power (min) | -12.66 dBmW |
| Rx power (max) | 2 dBmW |
| Sustainability compliance | Yes |
| Compliance certificates | RoHS, WEEE |
| Performance | |
| Product colour | Green, Metallic |
| Hot-swap | Yes |
| SFP transceiver type | Fiber optic |
| Tx wavelength (min) | 1295 nm |
| Tx wavelength (max) | 1325 nm |
| Rx wavelength (min) | 1295 nm |
| Rx wavelength (max) | 1325 nm |
| Fiber optic connector | LC |
| Maximum transfer distance | 2000 m |
| Tx power (min) | -9.4 dBmW |
| Tx power (max) | 2 dBmW |
| Rx power (min) | -12.66 dBmW |
| Rx power (max) | 2 dBmW |
| Maximum data transfer rate | 100000 Mbit/s |
| Interface type | QSFP |
| Single-mode fiber (SMF) supported | Yes |
| Features | |
| Product colour | Green, Metallic |
| Hot-swap | Yes |
| Power | |
| Power consumption (typical) | 3.5 W |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 60 °C |
| Storage temperature (T-T) | -40 - 85 °C |
Manufacturer
Cisco
