ATGBICS QDD-8X25-MR-SR-E Arista compatible Transceiver QSFP-DD 8x25G-SR|8x10G-SR low latency (850nm MMF 50/100/400m MPO-16 DOM)
QDD-8X25-MR-SR-E Arista compatible Transceiver QSFP-DD 8x25G-SR|8x10G-SR low latency (850nm MMF 50/100/400m MPO-16 DOM)
Part#:
QDD-8X25-MR-SR-E-C
Manufacturer:
ATGBICS
Excl. VAT: £416.00
Available to Backorder: contact for lead time
ATGBICS Arista compatible QDD-8X25-MR-SR-E QSFP-DD 200GBase-MR-SR form factor network transceiver supports a distance of up to 400m over multi-mode fibre (MMF) using a wavelength of 850nm via an MPO-16/APC connector. This product operates within a commercial temperature range. Digital optical monitoring (DOM) support is also present enabling real-time monitoring of the parameters of the fibre optic transceiver. Our product meets the specification of Arista QDD-8X25-MR-SR-E and we proudly offer a compatibility guarantee and limited lifetime warranty. Our rigorously tested products record a unique traceable serial number and are fully compliant with all MSA (Multi-Source Agreement) and IEEE standards & protocols.
More Information
Part#
QDD-8X25-MR-SR-E-C
Specification
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Ethernet LAN | Yes |
| Digital Diagnostics Monitoring (DDM) | Yes |
| Fiber optic connector | MPO-16 |
| Maximum transfer distance | 400 m |
| Wavelength | 850 nm |
| Maximum data transfer rate | 200000 Mbit/s |
| Interface type | QSFP-DD |
| Single-mode fiber (SMF) supported | No |
| Multi-mode fiber (MMF) supported | Yes |
| Ethernet interface type | 200 Gigabit Ethernet |
| SFP transceiver standard | SR8, SR |
| Fiber ethernet cabling technology | 200GBASE |
| Export Control Classification Number (ECCN) | 5A991 |
| Country of origin | China |
| Easy to install | Yes |
| Product colour | Silver |
| Housing material | Metal |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Brand compatibility | Arista Networks |
| Features | |
| Easy to install | Yes |
| Product colour | Silver |
| Housing material | Metal |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Brand compatibility | Arista Networks |
| Country of origin | China |
| Certification | CE, UKCA, EMC, FCC, REACH, RoHS, TÜV, FDA |
| Certificates | |
| Certification | CE, UKCA, EMC, FCC, REACH, RoHS, TÜV, FDA |
| Compliance certificates | TÜV mark, UKCA, UL, US FDA, REACH, Federal Communications Commission (FCC), RoHS, CE |
| Sustainability | |
| Doesn't contain | Lead |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Network | |
| SFP transceiver type | Fiber optic |
| Fiber optic connector | MPO-16 |
| Maximum data transfer rate | 200000 Mbit/s |
| Interface type | QSFP-DD |
| Ethernet interface type | 200 Gigabit Ethernet |
| Technical details | |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Maximum transfer distance | 400 m |
| Wavelength | 850 nm |
| Ethernet LAN | Yes |
| Doesn't contain | Lead |
| Compliance certificates | TÜV mark, UKCA, UL, US FDA, REACH, Federal Communications Commission (FCC), RoHS, CE |
| Packaging data | |
| Package type | Box |
| Packaging content | |
| Package type | Box |
| Logistics data | |
| Country of origin | China |
Manufacturer
ATGBICS
PDF Url
