HPE P02463-B21 - DL380 Gen10 4208 16G 12LFF Renew Svr
HPE ProLiant DL380 Gen10 4208 2.1GHz 8-core 1P 16GB-R S100i 12LFF 500W PS Renew Server
Part#:
P02463R-B21
Manufacturer:
HPE
Excl. VAT: £2,525.00
Available to Backorder: contact for lead time
HPE ProLiant DL380 Gen10 4208 2.1GHz 8-core 1P 16GB-R S100i 12LFF 500W PS Renew Server
More Information
Part#
P02463R-B21
Specification
| Processor | |
|---|---|
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Thermal Design Power (TDP) | 85 W |
| Tcase | 78 °C |
| Supported instruction sets | AVX-512 |
| Scalability | 2S |
| Processor threads | 16 |
| Processor package size | 76.0 x 56.5 mm |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Cascade Lake |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2400 MHz |
| Maximum number of PCI Express lanes | 48 |
| Maximum internal memory supported by processor | 1.02 TB |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| Processor cache type | Smart Cache |
| Processor cache | 11 MB |
| Processor frequency | 2.1 GHz |
| Processor boost frequency | 3.2 GHz |
| Number of processors installed | 1 |
| Processor model | 4208 |
| Processor socket | LGA 3647 (Socket P) |
| Processor cores | 8 |
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Silver |
| Memory | |
| Internal memory | 16 GB |
| Memory slots | 24x DIMM |
| Memory clock speed | 2933 MHz |
| Maximum internal memory | 768 GB |
| Internal memory type | DDR4-SDRAM |
| Buffered memory type | Registered (buffered) |
| Storage | |
| Supported HDD sizes | 3.5" |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
| Optical drive type | No |
| Number of HDDs supported | 12 |
| HDD size | 3.5" |
| Graphics | |
| On-board graphics card model | Not available |
| Network | |
| LAN controller | HP 331i |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 4 |
| DisplayPorts quantity | 1 |
| Expansion slots | |
| PCI Express slots version | 3.0 |
| Optical drive | |
| Optical drive type | No |
| Design | |
| Redundant fans support | Yes |
| Rack mounting | Yes |
| Optical drive type | No |
| Chassis type | Rack (2U) |
| Performance | |
| Compatible operating systems | Windows Server 2019 |
| Operating system installed | No |
| Software | |
| Compatible operating systems | Windows Server 2019 |
| Operating system installed | No |
| Processor special features | |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 193390 |
| Power | |
| Number of main power supplies | 1 |
| Redundant power supply (RPS) support | Yes |
| Power supply | 500 W |
| Technical details | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Supported HDD sizes | 3.5" |
| Redundant fans support | Yes |
| Rack mounting | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Chassis type | Rack (2U) |
| Sustainability certificates | ENERGY STAR |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Width | 445.5 mm |
| Weight | 14.8 kg |
| Height | 87.4 mm |
| Depth | 730.3 mm |
Manufacturer
HPE
