Cisco Meraki MS130-12X network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U White
L2, 8 - 10/100/1000 Mbps, RJ45, 802.3bt, PoE up to 30W per port, 2x 10 Gbe SFP+, DHCP Snooping, 802.1X Authentication, IPv4/6 ACL, SNMP/Syslog, 54 VDC, 5.56A, 4.4 x 23 x 23 cm, 1.06 kg
Part#:
MS130-12X
Manufacturer:
Cisco
Excl. VAT: £1,081.71
Available to Backorder: contact for lead time
Powerful full-size switch with optional PoE+ and mGig
High-performance switch optimized for medium to large campuses with Wi-Fi and IoT deployments.
Cisco Meraki MS130 switches provide Layer 2 access switching, ideal for branch and campus deployments. The MS130 series features a variety of options designed to meet the diverse needs of branch and campus deployments.
With 10 different models, capable of providing up to 740W of power over a variety of port densities, including SFP+ capable uplinks, the MS130 line is fully ready to support future wireless infrastructure deployments across a variety of different environments.
High-performance switch optimized for medium to large campuses with Wi-Fi and IoT deployments.
Cisco Meraki MS130 switches provide Layer 2 access switching, ideal for branch and campus deployments. The MS130 series features a variety of options designed to meet the diverse needs of branch and campus deployments.
With 10 different models, capable of providing up to 740W of power over a variety of port densities, including SFP+ capable uplinks, the MS130 line is fully ready to support future wireless infrastructure deployments across a variety of different environments.
More Information
Part#
MS130-12X
Specification
| Management features | |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L2 |
| Cloud-managed | Yes |
| Ports & interfaces | |
| SFP+ module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| 2.5G Ethernet (copper) ports quantity | 4 |
| Number of management ports | 1 pc(s) |
| Network | |
| Networking standards | IEEE 802.1x, IEEE 802.3bt |
| Spanning tree protocol | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| 10G support | No |
| Virtual LAN features | Voice VLAN |
| IGMP snooping | Yes |
| Data transmission | |
| Switching capacity | 76 Gbit/s |
| Security | |
| Authentication | MAC-based authentication |
| Security algorithms | SNMP |
| IGMP snooping | Yes |
| Authentication type | RADIUS |
| DHCP features | DHCP snooping |
| Multicast features | |
| Multicast support | Yes |
| Multicast features | Multicast traffic suppression |
| Protocols | |
| IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
| Design | |
| Form factor | 1U |
| Product colour | White |
| LED indicators | Yes |
| Rack mounting | Yes |
| Performance | |
| Firmware upgradeable | Yes |
| Power | |
| Power consumption (max) | 260 W |
| Power supply included | Yes |
| Input current | 5.56 A |
| DC input voltage | 54 V |
| Power source | AC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 240 W |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Virtual LAN features | |
| Virtual LAN features | Voice VLAN |
| Weight & dimensions | |
| Width | 230 mm |
| Depth | 230 mm |
| Height | 44 mm |
| Weight | 1.06 kg |
| IPv4 & IPv6 features | |
| IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
| Technical details | |
| Form factor | 1U |
| Product colour | White |
| Firmware upgradeable | Yes |
| Rack mounting | Yes |
| Indication | |
| LED indicators | Yes |
Manufacturer
Cisco
