ATGBICS MCX623106AN-CDAT-C network card Internal Ethernet 100000 Mbit/s
NVIDIA Mellanox MCX623106AN-CDAT, NVIDIA ConnectX-6, PCIe 4.0 x16, Dual Port, 100Gbps, 2x QSFP56, 142x69mm
Part#:
MCX623106AN-CDAT-C
Manufacturer:
ATGBICS
Excl. VAT: £496.00
Available to Backorder: contact for lead time
NVIDIA Mellanox® MCX623106AN-CDAT alternative ConnectX-6 Dx Smart NIC PCIe 4.0 x8 Dual Port 100GbE QSFP56
The PCIe x16 NVIDIA® ConnectX®-6 Dx Dual-Port 100G network adapter is a highly secure and advanced smart network interface card (SmartNIC) that accelerates mission critical cloud and data centre applications, including security, virtualization, SDN/NFV, big data, machine learning, and storage.
ConnectX®-6 Dx provides up to two ports of 100Gb/s.
Features virtual switch (vSwitch) and virtual router (vRouter) hardware accelerations.
Supports a choice of single-root I/O virtualization (SR-IOV) and VirtIO in hardware. By offloading cloud networking workloads, ConnectX-6 Dx frees up CPU cores for business applications.
The PCIe x16 NVIDIA® ConnectX®-6 Dx Dual-Port 100G network adapter is a highly secure and advanced smart network interface card (SmartNIC) that accelerates mission critical cloud and data centre applications, including security, virtualization, SDN/NFV, big data, machine learning, and storage.
ConnectX®-6 Dx provides up to two ports of 100Gb/s.
Features virtual switch (vSwitch) and virtual router (vRouter) hardware accelerations.
Supports a choice of single-root I/O virtualization (SR-IOV) and VirtIO in hardware. By offloading cloud networking workloads, ConnectX-6 Dx frees up CPU cores for business applications.
More Information
Part#
MCX623106AN-CDAT-C
Specification
| Ports & interfaces | |
|---|---|
| Internal | Yes |
| PCI version | 4.0 |
| Fiber ports quantity | 2 |
| Fiber optic connector | QSFP56 |
| PCI Card form factor | Full-height (low-profile) |
| Interface | Ethernet |
| Host interface | PCI Express |
| Connectivity technology | Wired |
| Bandwidth | |
| Maximum data transfer rate | 100000 Mbit/s |
| Network | |
| Chipset | NVIDIA ConnectX-6 |
| Ethernet interface type | 10 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, 50 Gigabit Ethernet, 100 Gigabit Ethernet, Gigabit Ethernet |
| Ethernet LAN | Yes |
| LAN controller | NVIDIA ConnectX-6 |
| Ethernet LAN data rates | 1000,2500,10000,40000,50000,100000 Mbit/s |
| Maximum data transfer rate | 100000 Mbit/s |
| Technical details | |
| Product colour | Green |
| PCI Card form factor | Full-height (low-profile) |
| Country of origin | China |
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
| Design | |
| Product colour | Green |
| Chipset | NVIDIA ConnectX-6 |
| Internal | Yes |
| PCI Card form factor | Full-height (low-profile) |
| Country of origin | China |
| Component for | PC/Server |
| Software | |
| Windows operating systems supported | Yes |
| System requirements | |
| Windows operating systems supported | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Weight & dimensions | |
| Width | 142 mm |
| Depth | 69 mm |
| Performance | |
| Windows operating systems supported | Yes |
| Other features | |
| Chipset | NVIDIA ConnectX-6 |
| Country of origin | China |
Manufacturer
ATGBICS
