HPE JZ878A - Aruba EC-L-H SD-WAN Gateway

HPE Aruba Networking EC-L-H 6x SFP+ 1/10G SD-WAN Gateway
Part#:
JZ878A
Manufacturer:
HPE
Excl. VAT: £25,064.00
Available to Backorder: contact for lead time
HPE Aruba Networking EdgeConnect SD-WAN provides a solid foundation for Zero Trust and SASE (Secure Access Service Edge) frameworks to tackle the networking and security challenges of hybrid working and cloud computing. The solution tightly integrates with HPE Aruba Networking SSE to form a single-vendor SASE platform. Leveraging a built-in next-generation firewall with features such as IDS/IPS, advanced Distributed Denial-of-Service (DDoS) protection and role-based segmentation, HPE Aruba Networking EdgeConnect SD-WAN enables organizations to seamlessly consolidate their branch equipment by replacing branch firewalls and routers. It allows them to reduce the cost and complexity of building a WAN while reducing MPLS dependency. This is achieved by leveraging broadband internet and cellular links to connect users to applications with advanced features such as path optimization, WAN optimization and multi-cloud networking.

What is new supporting point:
HPE Aruba Networking Central orchestrates the HPE Aruba Networking EdgeConnect SD-WAN fabric between EdgeConnect SD-WAN, EdgeConnect SD-Branch and EdgeConnect Microbranch.
HPE Aruba Networking EdgeConnect SD-WAN augmented with SWG helps organizations protect all users and things from web-based threats eliminating the need to install an SSE agent on each device.
Adaptive DDoS is an optional feature of HPE Aruba Networking EdgeConnect SD-WAN to protect branch locations against DDoS attacks by automatically adjusting DoS thresholds using machine learning.
More Information
Part#
JZ878A
EAN
0190017547930
Specification
Design
LED indicatorsLAN, WAN
CertificationEMC: FCC Part 15 Class A; EN 55022 Class A; EN 61000-3-2/3-3 Safety: EN 55024; L/cUL 60950 / 62368; EN 60950 / 62368
Mounting typeRack/Desktop/Wall
Rack capacity1U
Product colourBlack, Silver
Performance
Built-in processorYes
SSD capacity480 GB
CertificationEMC: FCC Part 15 Class A; EN 55022 Class A; EN 61000-3-2/3-3 Safety: EN 55024; L/cUL 60950 / 62368; EN 60950 / 62368
Mounting typeRack/Desktop/Wall
Rack capacity1U
Product colourBlack, Silver
Network
Networking standardsIEEE 802.1Q, IEEE 802.3z, IEEE 802.3ae
Ethernet LAN data rates10,100,1000,10000 Mbit/s
Security
VLAN supportYes
Firewall securityYes
Number of VLANs22
Ports & interfaces
WAN connectionEthernet (RJ-45)
USB 2.0 ports quantity1
I/O ports6 x 1/10 Gbps fiber LAN/WAN
Power
Power consumption (typical)404 W
Power over Ethernet (PoE)Yes
Input voltage100 - 240 V
Input frequency50/60 Hz
Heat dissipation1379 BTU/h
Power consumption (max)79.5 W
Power consumption (idle)5.6 W
Power over Ethernet (PoE) type supportedPoE+
Weight & dimensions
Weight14.6 kg
Width43 mm
Height707 mm
Depth435 mm
Operational conditions
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)15 - 95%
Technical details
Built-in processorYes
Weight (imperial)14.5 kg (32 lbs)
Indication
LED indicatorsLAN, WAN
Certificates
CertificationEMC: FCC Part 15 Class A; EN 55022 Class A; EN 61000-3-2/3-3 Safety: EN 55024; L/cUL 60950 / 62368; EN 60950 / 62368
Features
Built-in processorYes
Manufacturer
HPE
