HPE JZ347A - Aruba AP-535 (US) TAA Unified AP
Aruba Networking AP-535 (US) TAA Dual Radio 4x4 802.11ax Internal Antennas Unified Campus AP
Part#:
JZ347A
Manufacturer:
HPE
Excl. VAT: £1,938.00
Available to Backorder: contact for lead time
The HPE Aruba Networking 530 Series Campus Access Points provide Wi-Fi 6 connectivity for high-density deployments such as larger office spaces, training and meeting facilities, and hospitals. Providing up to 2.97 Gbps combined aggregate data rate, this series is built on Wi-Fi 6 standards (IEEE 802.11ax) and includes features such as OFDMA, bidirectional MU-MIMO, and target wait time (TWT) for better multi-user performance and improved efficiency. This series can be deployed using Zero Touch Provisioning, without on‑site technical expertise, for ease of implementation in branch offices and for remote work. HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and VPNs. AI‑powered analytics, end‑to‑end orchestration and automation, and advanced security features are built natively into the solution. The 530 Series includes a limited lifetime warranty.
What is new supporting point:
Wi-Fi 6 access points (APs) provide up to 2.97 Gbps combined aggregate data rate.
Dual radio AP supporting 5 GHz and 2.4 GHz bands (4x4 MIMO).
Protects network security with stronger encryption and authentication, secure credentials/keys storage, and user and IoT access policy enforcement firewalls (PEF).
Deploy models with internal antennas or connectorized models that support external antennas to meet range of environments.
IoT-ready with support for [1] Bluetooth 5 and Zigbee and two 5 Gbps ports for fast wired connectivity.
What is new supporting point:
Wi-Fi 6 access points (APs) provide up to 2.97 Gbps combined aggregate data rate.
Dual radio AP supporting 5 GHz and 2.4 GHz bands (4x4 MIMO).
Protects network security with stronger encryption and authentication, secure credentials/keys storage, and user and IoT access policy enforcement firewalls (PEF).
Deploy models with internal antennas or connectorized models that support external antennas to meet range of environments.
IoT-ready with support for [1] Bluetooth 5 and Zigbee and two 5 Gbps ports for fast wired connectivity.
More Information
Part#
JZ347A
EAN
0190017232867
Specification
Data transmission | |
---|---|
Ethernet LAN data rates | 100,1000,2500,5000 Mbit/s |
Maximum data transfer rate | 3550 Mbit/s |
Performance | |
2.4 GHz | Yes |
5 GHz | Yes |
Auto MDI/MDI-X | Yes |
Spread spectrum method | DSSS, OFDM |
Networking standards | IEEE 802.11ax |
Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Ethernet LAN data rates | 100,1000,2500,5000 Mbit/s |
Certification | None |
Maximum data transfer rate | 3550 Mbit/s |
MIMO type | Multi User MIMO |
MIMO | Yes |
Wireless LAN features | |
Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Network | |
Spread spectrum method | DSSS, OFDM |
Networking standards | IEEE 802.11ax |
Security | |
Cable lock slot | Yes |
Security algorithms | WMM, WPA, WPA2 |
Features | |
2.4 GHz | Yes |
5 GHz | Yes |
Auto MDI/MDI-X | Yes |
Spread spectrum method | DSSS, OFDM |
Networking standards | IEEE 802.11ax |
Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Ethernet LAN data rates | 100,1000,2500,5000 Mbit/s |
Maximum data transfer rate | 3550 Mbit/s |
MIMO type | Multi User MIMO |
MIMO | Yes |
Maximum data transfer rate (2.4 GHz) | 1148 Mbit/s |
Maximum data transfer rate (5 GHz) | 2402 Mbit/s |
Ports & interfaces | |
USB connector type | USB Type-A |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Power | |
Power consumption (max) | 23.3 W |
Power over Ethernet (PoE) | Yes |
Design | |
Placement | Ceiling, Wall |
Product colour | White |
Certification | None |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Antenna | |
Antenna type | Internal |
Antennas quantity | 4 |
Antenna gain level (max) | 5.4 dBi |
Antenna direction type | Omni-directional |
Antenna features | Integrated antenna |
Certificates | |
Certification | None |
Weight & dimensions | |
Width | 240 mm |
Depth | 240 mm |
Weight | 1 kg |
Height | 57 mm |
Operational conditions | |
Operating relative humidity (H-H) | 5 - 93% |
Operating temperature (T-T) | 0 - 50 °C |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 93% |
Manufacturer
HPE
