HPE JZ331A - Aruba AP-534 (RW) Unified AP
HPE Aruba Networking AP-534 (RW) Dual Radio 4x4 802.11ax External Antennas Unified Campus AP
Part#:
JZ331A
Manufacturer:
HPE
Excl. VAT: £1,118.50
RRP: £1,614.00
Save: 31%
Available to Backorder: contact for lead time
The Aruba 530 Series with 802.11ax (Wi-Fi 6), combined with Aruba intelligent software features are designed to deliver high performance connectivity in extreme density deployments of mobile and IoT devices.
The 530 Series is designed to simultaneously serve multiple clients and types of traffic, boosting overall network performance by up to 4X versus 802.11ac APs.
In addition to 802.11ax benefits, the 530 Series also provide Aruba differentiated capabilities that include AI-powered RF optimization, always-on connectivity and WPA3 certified security.
Additionally, Green AP mode for 802.11ax APs also leverages AI/ML capabilities for energy savings of up to 70%.
Enhanced performance
Aruba's ClientMatch feature intelligently groups Wi-Fi 6 clients onto the best AP's to leverage 802.11ax multi-user capabilities.
Smart power management
Aruba Intelligent Power Monitoring (IPM) allows APs to operate even if existing Ethernet switches lack adequate PoE power.
IoT and location ready
Leverage your Wi-Fi infrastructure to support Zigbee and Bluetooth use cases, devices and applications.
The 530 Series is designed to simultaneously serve multiple clients and types of traffic, boosting overall network performance by up to 4X versus 802.11ac APs.
In addition to 802.11ax benefits, the 530 Series also provide Aruba differentiated capabilities that include AI-powered RF optimization, always-on connectivity and WPA3 certified security.
Additionally, Green AP mode for 802.11ax APs also leverages AI/ML capabilities for energy savings of up to 70%.
Enhanced performance
Aruba's ClientMatch feature intelligently groups Wi-Fi 6 clients onto the best AP's to leverage 802.11ax multi-user capabilities.
Smart power management
Aruba Intelligent Power Monitoring (IPM) allows APs to operate even if existing Ethernet switches lack adequate PoE power.
IoT and location ready
Leverage your Wi-Fi infrastructure to support Zigbee and Bluetooth use cases, devices and applications.
More Information
Part#
JZ331A
EAN
0190017232706
Specification
Data transmission | |
---|---|
Ethernet LAN data rates | 100,1000,2500,5000 Mbit/s |
Maximum data transfer rate | 3550 Mbit/s |
Performance | |
2.4 GHz | Yes |
5 GHz | Yes |
Auto MDI/MDI-X | Yes |
Spread spectrum method | DSSS, OFDM |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3z |
Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Ethernet LAN data rates | 100,1000,2500,5000 Mbit/s |
Maximum data transfer rate | 3550 Mbit/s |
MIMO | Yes |
Wireless LAN features | |
Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Network | |
Spread spectrum method | DSSS, OFDM |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3z |
Security | |
Cable lock slot | Yes |
Security algorithms | WMM, WPA, WPA2 |
Features | |
2.4 GHz | Yes |
5 GHz | Yes |
Auto MDI/MDI-X | Yes |
Spread spectrum method | DSSS, OFDM |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3z |
Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Ethernet LAN data rates | 100,1000,2500,5000 Mbit/s |
Maximum data transfer rate | 3550 Mbit/s |
MIMO | Yes |
Maximum data transfer rate (2.4 GHz) | 1148 Mbit/s |
Maximum data transfer rate (5 GHz) | 2402 Mbit/s |
Ports & interfaces | |
USB connector type | USB Type-A |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Power | |
Power consumption (max) | 23.3 W |
Power over Ethernet (PoE) | Yes |
Design | |
Placement | Ceiling, Wall |
Product colour | White |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Antenna | |
Number of connectors | 4 |
Antenna type | External |
Antennas quantity | 4 |
Antenna connector type | RP-SMA |
Technical details | |
Harmonized System (HS) code | 85176990 |
Weight & dimensions | |
Width | 240 mm |
Depth | 240 mm |
Weight | 1.27 kg |
Height | 57 mm |
Operational conditions | |
Operating relative humidity (H-H) | 5 - 93% |
Operating temperature (T-T) | 0 - 50 °C |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 93% |
Logistics data | |
Harmonized System (HS) code | 85176990 |
Manufacturer
HPE
