HPE JL823A - 5140 24G POE+ 2SFP+ 2XGT Renew EI Sw
HPE Networking Comware Switch 24G POE+2SFP+2XGT Renew EI 5140
Part#:
JL823AR
Manufacturer:
HPE
Excl. VAT: £4,599.00
Available to Backorder: contact for lead time
HPE Networking Comware Switch 24G POE+2SFP+2XGT Renew EI 5140
More Information
Part#
JL823AR
Specification
Management features | |
---|---|
Multicast support | Yes |
Switch type | Managed |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch layer | L3 |
Network | |
IGMP snooping | Yes |
IPv6 FIB entries | 256 |
IPv4 FIB entries | 512 |
Auto-sensing | Yes |
Networking standards | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Full duplex | Yes |
VLAN support | Yes |
Spanning tree protocol | Yes |
Port mirroring | Yes |
Link aggregation | Yes |
Flow control support | Yes |
Broadcast storm control | Yes |
Auto MDI/MDI-X | Yes |
10G support | Yes |
Virtual LAN features | |
VLAN support | Yes |
IPv4 & IPv6 features | |
IPv6 FIB entries | 256 |
IPv4 FIB entries | 512 |
Performance | |
Stackable | Yes |
Physical stacking (units) | 9 |
Memory type | SDRAM |
Internal memory | 512 MB |
Flash memory | 256 MB |
Harmonized System (HS) code | 85176990 |
Technical details | |
Physical stacking (units) | 9 |
Form factor | 1U |
Stackable | Yes |
Rack mounting | Yes |
Ports & interfaces | |
SFP+ module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Console port | RJ-45 |
Data transmission | |
Throughput | 96 Mpps |
Latency (1 Gbps) | 5 µs |
Latency (10 Gbps) | 3 µs |
MAC address table | 16384 entries |
Switching capacity | 128 Gbit/s |
Jumbo frames support | Yes |
Security | |
Authentication | MAC-based authentication |
IGMP snooping | Yes |
Access Control List (ACL) | Yes |
Authentication type | HWTACACS, RADIUS |
DHCP features | DHCP server |
Multicast features | |
Multicast support | Yes |
Protocols | |
Routing protocols | OSPF, OSPFv2, OSPFv3, RIP, RIP-2 |
IPv6 FIB entries | 256 |
IPv4 FIB entries | 512 |
Memory | |
Memory type | SDRAM |
Internal memory | 512 MB |
Flash memory | 256 MB |
Design | |
Form factor | 1U |
Stackable | Yes |
Rack mounting | Yes |
Power | |
Power consumption (max) | 420 W |
Power supply included | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power source | AC |
Power over Ethernet (PoE) | |
Total Power over Ethernet (PoE) budget | 370 W |
Power over Ethernet (PoE) | Yes |
Operational conditions | |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | -5 - 45 °C |
Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions | |
Width | 440 mm |
Depth | 320 mm |
Height | 43.6 mm |
Weight | 4.5 kg |
Logistics data | |
Harmonized System (HS) code | 85176990 |
Manufacturer
HPE
