HPE JL705C - Aruba 8360-48Y6C v2 BF 5F 2AC Bdl
Aruba Networking CX 8360-48Y6C v2 48p 25G SFP28 4Sec 6p 100G QSFP+ 2Sec BF 5 Fans 2AC Bundle
Part#:
JL705C
Manufacturer:
HPE
Excl. VAT: £26,700.60
RRP: £38,891.00
Save: 31%
Available to Backorder: contact for lead time
The HPE Aruba Networking CX 8360 v2 Switch Series are designed for next-generation core and aggregation layer of campuses, as well as virtual and highly dynamic data center environments. Provide up to 4.8 Tbps switching capacity, with line-rate Gigabit Ethernet interfaces including support for HPE Smart Rate (1/2.5, 5 Gbps), 10 Gbps, 25 Gbps, 40 Gbps, 50 Gbps, and 100 Gbps connectivity in a compact 1U form factor. These switches deliver a fantastic investment for customers wanting to migrate from older 1 GbE/10 GbE to faster 25 GbE, or from 10 GbE/40 GbE uplinks to 50/100 GbE ports. In addition, the 48 and 32 x 25G port CX 8360 models support low-density MACsec ports and enable secured connectivity at 10 GbE and 25 GbE over unsecured domains. MACsec is also supported on 2 high-speed 40/100 G ports on the CX 8360 48-port model.
What is new supporting point:
Intelligent monitoring and visibility delivered by the HPE Aruba Networking Network Analytics Engine (NAE)
High availability with industry-leading VSX redundancy and redundant power supplies and fans.
48-port 1/10/25 G with 4 MACsec, 6-port of 40/100 G with 2 MACsec. MACsec secured connectivity over untrusted domains.
High-performance 4.8 Tbps and 2,678 Mpps. 50G support on 8360-48Y6C, 32Y4C and 16Y2C switches. Addition of HPE Smart Rate (1/2.5/5/10 G) ports on the 836048XT4C
What is new supporting point:
Intelligent monitoring and visibility delivered by the HPE Aruba Networking Network Analytics Engine (NAE)
High availability with industry-leading VSX redundancy and redundant power supplies and fans.
48-port 1/10/25 G with 4 MACsec, 6-port of 40/100 G with 2 MACsec. MACsec secured connectivity over untrusted domains.
High-performance 4.8 Tbps and 2,678 Mpps. 50G support on 8360-48Y6C, 32Y4C and 16Y2C switches. Addition of HPE Smart Rate (1/2.5/5/10 G) ports on the 836048XT4C
More Information
Part#
JL705C
EAN
0190017567907
Specification
| Management features | |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L3 |
| Ports & interfaces | |
| SFP+ module slots quantity | 48 |
| QSFP+ module slots quantity | 6 |
| Basic switching RJ-45 Ethernet ports quantity | 0 |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Fiber optic connector | QSFP+, QSFP28, SFP, SFP+, SFP28 |
| Console port | RJ-45/USB Type-C |
| Network | |
| Networking standards | IEEE 802.1AE, IEEE 802.1AX, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3ba, IEEE 802.3by, IEEE 802.3cc, IEEE 802.3cd, IEEE 802.3x, IEEE 802.3z |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Port mirroring | Yes |
| Number of VLANs | 4094 |
| Link aggregation | Yes |
| Flow control support | Yes |
| 10G support | Yes |
| Virtual LAN features | Private VLAN |
| IGMP snooping | Yes |
| IGMP entries | 7000 |
| Data transmission | |
| Throughput | 2678 Mpps |
| Packet buffer memory | 32 MB |
| MAC address table | 212992 entries |
| Switching capacity | 4800 Gbit/s |
| Jumbo frames support | Yes |
| Static route | Yes |
| Number of VLANs | 4094 |
| Security | |
| SSH/SSL support | Yes |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Authentication type | RADIUS, TACACS+ |
| IGMP entries | 7000 |
| DHCP features | DHCP relay, DHCP server |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Routing protocols | RIP-2 |
| Design | |
| Form factor | 1U |
| Rack mounting | Yes |
| Airflow direction | Back-to-front airflow |
| Number of fans | 5 fan(s) |
| Redundant fans support | Yes |
| Performance | |
| Processor frequency | 1800 MHz |
| Memory type | RAM / Flash |
| Internal memory | 16384 MB |
| Flash memory | 32000 MB |
| Built-in processor | Yes |
| Packet buffer memory | 32 MB |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power consumption (max) | 725 W |
| Power supply included | Yes |
| AC input voltage | 200 - 240 V |
| AC input frequency | 47/63 Hz |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| Power source | AC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 15 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 15 - 95% |
| Operating altitude | 0 - 3048 m |
| Heat dissipation | 1.45 BTU/h |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 4094 |
| Virtual LAN features | Private VLAN |
| Weight & dimensions | |
| Width | 44 mm |
| Depth | 44.2 mm |
| Height | 559 mm |
| Weight | 10.7 kg |
| Optical fiber | |
| Fiber optic connector | QSFP+, QSFP28, SFP, SFP+, SFP28 |
| Technical details | |
| Form factor | 1U |
| Processor frequency | 1800 MHz |
| Rack mounting | Yes |
| Built-in processor | Yes |
| Memory | |
| Packet buffer memory | 32 MB |
| Memory type | RAM / Flash |
| Internal memory | 16384 MB |
| Flash memory | 32000 MB |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
Manufacturer
HPE
