HPE JH390A - FF 5940 48SFP+ 6QSFP28 Switch
HPE Networking Comware Switch 48SFP+ 6QSFP28 5940
Part#:
JH390A
Manufacturer:
HPE
Excl. VAT: £18,306.96
RRP: £26,344.00
Save: 31%
Available to Backorder: contact for lead time
The HPE FlexFabric 5940 Switch Series is a family of high-performance and low-latency 10GbE and 40GbE top-of-rack (ToR) data center switches. The 5940 Switch includes 100G uplink technology which is part of the HPE FlexFabric data center solution and is a cornerstone of the FlexNetwork architecture. The 5940 Switch is suited for deployment at the aggregation or server access layer of large enterprise data centers or at the core layer of medium-sized enterprises. It is optimized for high-performance server connectivity, convergence of Ethernet and storage traffic, and virtual environments.
What is new supporting point:
Comware 7 advanced modular operating system designed for high availability.
EVPN, OpenFlow and SDN automate manual tasks and speed service delivery.
IRF supports of up to nine switches simplifies management by up to 88%.
Pre-configured switch bundles for deployment in the campus aggregation and core.
VXLAN Layer 2 and Layer 3 gateway support.
HPE FlexFabric Network Analytics solution provides network visibility and all information to run the network at its optimal performance.
What is new supporting point:
Comware 7 advanced modular operating system designed for high availability.
EVPN, OpenFlow and SDN automate manual tasks and speed service delivery.
IRF supports of up to nine switches simplifies management by up to 88%.
Pre-configured switch bundles for deployment in the campus aggregation and core.
VXLAN Layer 2 and Layer 3 gateway support.
HPE FlexFabric Network Analytics solution provides network visibility and all information to run the network at its optimal performance.
More Information
Part#
JH390A
EAN
0190017014821
Specification
| Management features | |
|---|---|
| Traffic shaping | Yes |
| Traffic classification | Yes |
| ARP inspection | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L2/L4 |
| Ports & interfaces | |
| SFP+ module slots quantity | 48 |
| QSFP+ module slots quantity | 6 |
| Basic switching RJ-45 Ethernet ports type | No |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Gigabit Ethernet (copper) ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| Fiber optic connector | SFP+ |
| Console port | RJ-45 |
| I/O ports | (48) fixed 1000/10000 SFP+ ports (6) QSFP28 100GbE ports |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u |
| 10G support | Yes |
| Optical fiber | |
| Fiber ethernet cabling technology | 10GBASE-R |
| Fiber optic connector | SFP+ |
| Data transmission | |
| Throughput | 1607 Mpps |
| Latency (10 Gbps) | 1 µs |
| Packet buffer memory | 12.2 MB |
| MAC address table | 288000 entries |
| Switching capacity | 2160 Gbit/s |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Management protocols | IMC |
| Design | |
| Form factor | 1U |
| Product colour | Black |
| Stackable | Yes |
| LED indicators | Yes |
| Rack mounting | Yes |
| Performance | |
| Physical stacking (units) | 9 |
| Internal memory | 4096 MB |
| Flash memory | 1024 MB |
| Packet buffer memory | 12.2 MB |
| Stackable | Yes |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power consumption (max) | 196 W |
| Power supply included | No |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (typical) | 196 W |
| Input voltage | -40 - -75 V |
| DC input voltage | 40 - 60 V |
| Power consumption note | 196 W (maximum) |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Other features | |
| Latency | 10 Gbps Latency: < 1 µs |
| Performance management | IMC - Intelligent Management Center Command-line interface Out-of-band management SNMP manager Telnet FTP |
| Memory and processor | 1 GB flash Packet buffer size: 16 MB 4 GB SDRAM |
| Weight (imperial) | 11 kg (24.2 lbs) |
| Non-operating relative humidity (non-condensing) | 10 - 90% |
| I/O ports | (48) fixed 1000/10000 SFP+ ports (6) QSFP28 100GbE ports |
| Dimensions (W x D x H) (imperial) | 439.9 x 460 x 43.7 mm (17.3 x 18.1 x 1.72") |
| Warranty period | 1 year(s) |
| Input voltage | -40 - -75 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 887 BTU/h |
| Non-operating relative humidity (non-condensing) | 10 - 90% |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 460 mm |
| Height | 43.6 mm |
| Weight | 11 kg |
| Weight (imperial) | 11 kg (24.2 lbs) |
| Dimensions (W x D x H) (imperial) | 439.9 x 460 x 43.7 mm (17.3 x 18.1 x 1.72") |
| Packaging content | |
| Quick start guide | Yes |
| User guide | Yes |
| Manual | Yes |
| Technical details | |
| Physical stacking (units) | 9 |
| Form factor | 1U |
| Product colour | Black |
| Stackable | Yes |
| Rack mounting | Yes |
| Warranty period | 1 year(s) |
| Memory | |
| Packet buffer memory | 12.2 MB |
| Internal memory | 4096 MB |
| Flash memory | 1024 MB |
| Indication | |
| LED indicators | Yes |
| Packaging data | |
| Quick start guide | Yes |
| User guide | Yes |
| Manual | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
