ATGBICS FTLF8519F2MNL-C network transceiver module Fiber optic 2000 Mbit/s SFP 850 nm
FTLF8519F2MNL Finisar Compatible Transceiver SFP 1000Base-SX (850nm, MMF, 550m, Ext Temp)
Part#:
FTLF8519F2MNL-C
Manufacturer:
ATGBICS
Excl. VAT: £94.00
Available to Backorder: contact for lead time
ATGBICS FTLF8519F2MNL 1000Base-SX supports a distance of up to 550m over multi-mode fibre (MMF) using a wavelength of 850nm via an LC connector. Digital optical monitoring (DOM) support is also present enabling real-time monitoring of the parameters of the fibre optic transceiver. It is a hot-swappable input/output device that plugs into a Gigabit Ethernet port/slot, linking the port with the fibre-optic network. Our product meets the specification of Finisar FTLF8519F2MNL= and we proudly offer a compatibility guarantee and lifetime warranty. Our rigorously tested products record a unique traceable serial number and are fully compliant with all MSA Standards.
More Information
Part#
FTLF8519F2MNL-C
EAN
5056468772862
Specification
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Ethernet LAN | Yes |
| Wavelength-division multiplexing (WDM) | No |
| Digital Diagnostics Monitoring (DDM) | Yes |
| Fiber optic connector | LC |
| Maximum transfer distance | 550 m |
| Wavelength | 850 nm |
| Maximum data transfer rate | 2000 Mbit/s |
| Interface type | SFP |
| Single-mode fiber (SMF) supported | No |
| Multi-mode fiber (MMF) supported | Yes |
| Ethernet interface type | Gigabit Ethernet |
| SFP transceiver standard | SX |
| Country of origin | China |
| Easy to install | Yes |
| Product colour | Silver |
| Housing material | Metal |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Brand compatibility | Finisar |
| Features | |
| Easy to install | Yes |
| Product colour | Silver |
| Housing material | Metal |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Brand compatibility | Finisar |
| Country of origin | China |
| Certification | CE, FCC, RoHS |
| Power | |
| Maximum voltage | 3.5 V |
| Input voltage | 3.3 V |
| Power consumption (typical) | 0.8 W |
| Certificates | |
| Certification | CE, FCC, RoHS |
| Compliance certificates | RoHS |
| Sustainability | |
| Sustainability compliance | Yes |
| Doesn't contain | Lead |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 85 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Minimum operating temperature | -5 °C |
| Maximum operating temperature | 85 °C |
| Network | |
| SFP transceiver type | Fiber optic |
| Fiber optic connector | LC |
| Maximum data transfer rate | 2000 Mbit/s |
| Interface type | SFP |
| Ethernet interface type | Gigabit Ethernet |
| Weight & dimensions | |
| Width | 13.4 mm |
| Depth | 56.5 mm |
| Height | 8.5 mm |
| Weight | 20 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Package type | Box |
| Technical details | |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Maximum transfer distance | 550 m |
| Wavelength | 850 nm |
| Ethernet LAN | Yes |
| Sustainability compliance | Yes |
| Doesn't contain | Lead |
| Compliance certificates | RoHS |
| Packaging data | |
| Package type | Box |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Country of origin | China |
Manufacturer
ATGBICS
