SFP 1GE CWDM 1610 NM TRANSCEIVER
SFP, 1000BASE-LX, 1610 nm, SMF 80 km, Standard Temperature (0 through 70 DEGREE C), Duplex LC connector
Part#:
EX-SFP-GE80KCW1610
Manufacturer:
Juniper
Excl. VAT: £1,091.08
RRP: £2,781.00
Save: 61%
Available to Backorder: contact for lead time
This is an optional uplink module for EX4200 switches support SFP, SFP+, or XFP transceivers. The Gigabit Ethernet SFP, SFP+, or XFP transceivers installed in EX4200 switches support digital optical monitoring (DOM). Use only optical transceivers and optical connectors purchased from Juniper Networks for your EX Series switches.
More Information
Part#
EX-SFP-GE80KCW1610
Specification
| Network | |
|---|---|
| SFP transceiver type | Fiber optic |
| Fiber optic connector | LC |
| Fiber ports quantity | 1 |
| Cabling technology | 1000BASE-LX |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | SFP |
| Technical details | |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Auto MDI/MDI-X | Yes |
| Maximum transfer distance | 80000 m |
| Wavelength | 1610 nm |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| Tx power (max) | 5 dBmW |
| Rx power (min) | -32 dBmW |
| Rx power (max) | -8 dBmW |
| Compatible products | Juniper EX4200 |
| Cabling technology | 1000BASE-LX |
| Ports & interfaces | |
| Fiber ports quantity | 1 |
| Performance | |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Compatible products | Juniper EX4200 |
| SFP transceiver type | Fiber optic |
| Fiber optic connector | LC |
| Auto MDI/MDI-X | Yes |
| Maximum transfer distance | 80000 m |
| Wavelength | 1610 nm |
| Fiber ports quantity | 1 |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| Tx power (max) | 5 dBmW |
| Rx power (min) | -32 dBmW |
| Rx power (max) | -8 dBmW |
| Cabling technology | 1000BASE-LX |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | SFP |
| Single-mode fiber (SMF) supported | Yes |
| SFP transceiver standard | LX |
| Features | |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Certification | MSA |
| Compatible products | Juniper EX4200 |
| Power | |
| Input voltage | 3.3 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 10 - 85% |
| Certificates | |
| Certification | MSA |
Manufacturer
Juniper
