SFP 1GE CWDM 1570 NM TRANSCEIVER
SFP, 1000BASE-LX, 1570 nm, SMF 80 km, Standard Temperature (0 through 70 DEGREE C), Duplex LC connector
Part#:
EX-SFP-GE80KCW1570
Manufacturer:
Juniper
Excl. VAT: £1,141.75
RRP: £2,794.00
Save: 59%
Available to Backorder: contact for lead time
This is an optional uplink module for EX4200 switches support SFP, SFP+, or XFP transceivers. The Gigabit Ethernet SFP, SFP+, or XFP transceivers installed in EX4200 switches support digital optical monitoring (DOM).
Use only optical transceivers and optical connectors purchased from Juniper Networks for your EX Series switches.
Use only optical transceivers and optical connectors purchased from Juniper Networks for your EX Series switches.
More Information
Part#
EX-SFP-GE80KCW1570
Specification
| Network | |
|---|---|
| SFP transceiver type | Fiber optic |
| Fiber optic connector | LC |
| Fiber ports quantity | 1 |
| Cabling technology | 1000BASE-LX |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | SFP |
| Technical details | |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Auto MDI/MDI-X | Yes |
| Maximum transfer distance | 80000 m |
| Wavelength | 1570 nm |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| Tx power (max) | 5 dBmW |
| Rx power (min) | -32 dBmW |
| Rx power (max) | -8 dBmW |
| Compatible products | Juniper EX4200 |
| Cabling technology | 1000BASE-LX |
| Ports & interfaces | |
| Fiber ports quantity | 1 |
| Performance | |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Compatible products | Juniper EX4200 |
| SFP transceiver type | Fiber optic |
| Fiber optic connector | LC |
| Auto MDI/MDI-X | Yes |
| Maximum transfer distance | 80000 m |
| Wavelength | 1570 nm |
| Fiber ports quantity | 1 |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| Tx power (max) | 5 dBmW |
| Rx power (min) | -32 dBmW |
| Rx power (max) | -8 dBmW |
| Cabling technology | 1000BASE-LX |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | SFP |
| Single-mode fiber (SMF) supported | Yes |
| SFP transceiver standard | LX |
| Features | |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Certification | MSA |
| Compatible products | Juniper EX4200 |
| Power | |
| Input voltage | 3.3 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 10 - 85% |
| Certificates | |
| Certification | MSA |
Manufacturer
Juniper
